Neolt Factory XY DTF Trimmer
Neolt Factory XY DTF Trimmer – Precision Cutting for DTF Printing
Take your Direct-to-Film (DTF) production to the next level with the Neolt Factory XY DTF Trimmer, engineered to fully automate trimming workflows with precision and efficiency. Designed specifically for DTF and flexible media, this system streamlines cutting while maintaining consistent, high-quality results.
Key Features
-
Automated XY Cutting System
Fully automatic horizontal and vertical cutting for precise, square trimming of DTF prints. -
Dual Cutting Modes
- Automatic Mode: Program size and number of copies
- Cut Marks Mode: Sensor-based cutting using printed registration lines
-
Integrated Compressor System
Built-in compressor powers pneumatic pinch rollers and vertical cutting units, with adjustable pressure for different materials -
Mechanical Alignment Adjustment
Manual roll alignment correction ensures accurate tracking during cutting -
Touchscreen Control Interface
Intuitive operation with programmable settings and guided workflows
Specifications (Corrected)
-
Maximum Cutting Width:
800–850 mm (31–33 in) -
Maximum Cutting Length:
Roll-fed (continuous operation) -
Cutting Speed:
Up to approx. 15 m/min (49.2 ft/min) depending on configuration -
Power Supply:
230V / 50 Hz -
Machine Dimensions:
Approx. 1600 × 600 × 600 mm (63 × 24 × 24 in) -
Media Handling:
Designed for DTF, HTV, and flexible roll media
Benefits
- Fully automates DTF trimming to reduce manual labor
- Improves production consistency and accuracy
- Optimized for ~30 in class DTF workflows (not wide-format 63 in systems)
- Adjustable cutting pressure enables processing of different media types
- Seamlessly integrates into roll-to-roll DTF production setups
